SVC4P25
4MP 25X Motorized Zoom AI Ultra-Range Full Color Night Vision PTZ Camera
Features
1/1.8'' Ultra-Starlight Grade CMOS
Dual-core ARM Cortex A55
f=7.1~171mm, 25X Optical Zoom, 4X Digital Zoom
WDR 120dB
Horizontal 360° Continuous Rotation; Vertical (-90°~+30°)
Color 5*10^-3lux (0.005 lux)
Ultra-Range Monitoring up to 5KM-10KM
Overview
The SVC4P25 4MP 25x AI Blacklight Full-Color Ball Camera utilizes a "1/1.8-inch" large target high-sensitivity image sensor, processed through AI ISP image engine, to achieve high-definition full-color imaging in low-light environments. Suitable for night- time monitoring that requires a wide range and long distance, it can be widely used in complex urban low-light environments and outdoor weak light environments, such as river surfaces, border, sea defense, forests, mines, etc. With the optical zoom lens, it can achieve both wide-angle monitoring of large scenes and detailed monitoring with telephoto.
Application Scenarios
Smart City, High-Point Monitoring, Forest Fire Prevention, Border and Coastal, Defense Monitoring, Water Affairs and Environmental Protection, Land and Resources Monitoring
Specification Parameters
Lens Parameters | |
Focal Length | f=7.1~171mm, 25X Optical Zoom, 4X Digital Zoom |
Aperture | F/1.6 ~ 5.1 |
Field of View | Horizontal: 58.4° Wide; 2.1° Tele; Vertical: 34.1° Wide; 1.2° Tele; Diagonal: 65.5° Wide; 2.4° Tele |
Day/Night Mode | Motorized IR-CUT Infrared Filter |
Focus Strategy | Auto, Semi-Auto, Manual |
Performance Parameters | |
Image Sensor | 1/1.8'' Ultra-Starlight Grade CMOS |
Chip Performance | Dual-core ARM Cortex A55@850MHz (3 DMIPS/MHz), 32KB I-Cache, built-in NPU processing engine |
Minimum Illumination | Color 5*10^-3lux (0.005 lux) |
Resolution | Main Stream: 2688*1520@25fps, 2560*1440@25fps, 1920*1080@25fps; Sub Stream: 704*576@25fps, 640*480@25fps |
Video Frame Rate | 25fps Real-time, 10~25fps Adaptive |
Video Compression | H.265/H.264 |
Video Storage | Supports SD card recording, supports automatic loop overwrite |
White Balance | Auto |
Gain Control | Auto |
Wide Dynamic Range | 120dB |
Exposure Mode | Auto |
AI ISP Image Engine | AI Night Vision Enhancement, AI Hyper Sensitivity Noise Reduction, AI Super HDR |
PTZ Parameters | |
Horizontal and Vertical Range | Horizontal 360° Continuous Rotation; Vertical (-90°~+30°) No Blind Spots |
Rotation Speed | Horizontal: 0.4°～200°/s, Vertical: 0.4°～100°/s |
Rotation Precision | ±0.025° |
Pre-set Points | 255 |
Focal Speed Matching | Control speed automatically adjusts according to focal length |
Scheduled Tasks | Supports scheduled task pre-set points, endurance scanning, left-right scanning |
Network Parameters | |
Network Protocol | IPv4/IPv6, HTTP, NTP, RTSP, RTCP, RTP, TCP/IP, UDP |
Video Protocol | ONVIF/GB28181/RTSP |
Browser | Supports edge, Chrome, Firefox browsers |
Algorithm Applications | |
Intelligent Events | Off-post Detection, Electronic Fencing, Person Recognition, Face Detection, Full Target Detection, License Plate Recognition (not included by default) |
Push Protocol | GAT1400/web socket/HTTP |
Peripheral Interfaces | |
Network Interface | RJ45 port, auto-negotiation 10M/100M network |
SD Card Interface | Supports Micro SD card storage (up to 256G, built-in interface) |
Optional Interfaces | Audio Input, Audio Output, I/O Input, I/O Output, RS485 (not included by default) |
General Specifications | |
Power & Power Consumption | DC 12V/4A (standard configuration) & MAX: 6w |
Housing Material | Metal |
Protection Level | Waterproof level: IP66, TVS3000V lightning protection, surge protection, voltage surge protection |
Operating Temperature and Humidity | -20℃~60℃, humidity less than 95% (no condensation) |
Packing Size | 265*265*420 mm |
Weight | <5.6KG |
Installation Methods | Wall mounting, ceiling suspension, column mounting |
